More Than Just Boring: A Detailed Look at the Multi-Function Machining Modes of Xinda Portable Boring Machines

On-site hole repair might appear, on the surface, to be a single action—bring an out-of-round or worn bore back to the correct dimension. In practice, however, boring is rarely an isolated step; it is usually linked to a chain of pre- and post-processing tasks: first treating the worn surface (repair welding/cleaning), then restoring the internal geometry, and finally addressing the sealing contact surface of the hole’s face. If each of these steps requires dismantling and repositioning the equipment, errors accumulate and time costs rise.

Multi-function Dimension 1: Repair Welding + Boring Completed on the Same Platform

For vulnerable components such as hinge holes in construction machinery or slewing bearing mounting holes, the typical process route is: build up the worn area by welding → restore dimensions and roundness by boring.

The corresponding solution offered by Xinda is the XDT50 Boring & Welding All-in-One Machine: welding repair and boring are performed within the same positioning system. Its specifications indicate a welding hole range of approx. φ50–230 mm, single-side weld thickness of about 4–5 mm, and post-weld direct transfer to boring, which covers approx. φ55–260 mm, achieving roundness of 0.02 mm and surface roughness Ra 3.2.

Multi-function Dimension 2: Restoring the Bore While Also Addressing the Outer Face

In many field cases, the core problem is not the bore diameter itself, but deformation or damage to the hole’s face that causes poor sealing or contact. Xinda lists, among the optional upgrades for the XDT40/50, a face milling/turning attachment​ (for repairing the outer face of the hole, applicable range approx. 70–230 mm), along with standard items such as centering taper sleeves and different tool holders. This allows users to include face restoration in the same setup without disturbing the original installation.

For buyers, the guiding principle here is: if the failure symptoms include “face gouging / uneven wear / deep washer imprints,” do not select equipment based solely on “internal boring capability.” Instead, confirm whether the face milling attachment can be fitted and whether the centering method still ensures coaxiality—this often matters more for assembly quality than an extra 0.5 mm of cutting depth.

Xinda also offers a practical modular approach in the XDT40/50 series:

30 mm boring bar accessory:​ extends the XDT50 minimum machining range down from 55 mm to approx. 35 mm;

Extended tool holder:​ pushes the maximum machining range from 260 mm up to approx. 300 mm;

The XDT50 welding & boring all-in-one model also retains two controller formats (pendant control / PLC CNC screen) to suit different site preferences.

Moving up in capacity, the XDT60​ uses a φ60 mm boring bar covering φ65–500 mm, and offers two drive options: a worm-gear electric version (servo motor + reducer) and a hydraulic motor version (with an 18.5 kW pump station). Lubrication is described as quantitative centralized lubrication—essentially telling customers that “multi-function” refers not only to combined machining actions, but also to matching the power solution to the site’s available energy sources.

One-Line Buying Recommendation

If you are evaluating portable boring solutions, start by mapping out your process route:

Is repair welding needed?

Is face machining needed?

Single hole or multiple coaxial holes?

Minimum and maximum bore diameters?

Power supply: 220 V or 380 V?

Once this chain is aligned, check against the specification table whether the machining roundness class (0.02 mm / 0.05 mm / 0.10 mm) and travel range meet your needs. You will find that so-called “multi-function machining capability” is essentially the equipment’s ability to reliably carry out your entire process chain.

(This article is compiled from publicly available corporate information and industry references for reference only. Specific product data and service terms are subject to the manufacturer’s official documentation.)
